The Systemizing Solution Supplier of Cable & Connector
| Place of Origin: | CHINA |
|---|---|
| Brand Name: | LYCN |
| Certification: | ROHS/UL/SGS |
| Model Number: | 2242 |
| Minimum Order Quantity: | 1000PCS |
| Price: | Negotiation |
| Packaging Details: | TRAY/TUBE/REEL |
| Delivery Time: | 20-30 Days |
| Payment Terms: | T/T, Western Union, MoneyGram |
| Supply Ability: | 8000000Kpcs |
| Current Rating: | 2.0AMP | Contact Resistance: | 20mΩ Max |
|---|---|---|---|
| Insulation Resustance: | 1000mΩ Min | Withstand Voltage: | 500V AC/MINUTE |
| Operation Temperature: | ﹣40℃ To +105℃ | Contact Material: | Copper Alloy |
| High Light: | 2×13 Pin Female Header Connector,2.0mm Pitch Female Header Connector |
||
2×13P Pins DIP Female Header Connector 2.0 Mm Pitch Current Rating 2.0 AMP
Products Application
Wide Appliction:All of our prodcuts can be widely used in electronics, electrical appliances, instrument connection device, which mainly plays the role of a current or signal transmission.
PCB Connectors are known as PCB Interconnect product. Specific terms are also used for the two sides of the connection. There are also some other names for PCB connectors: Male PCB Connectors usually referred to Pin Headers, as they are simply rows of pins, while Female PCB Connectors named as Sockets, Receptacles, or even (somewhat confusingly) Header Receptacles.
Generally, female headers with suited pin headers are used to finish created modules in electronic industry.As above you can find some of scope of application.
Why choose us
1. High-Quality Guarantee
LYCN has been focusing on improving the Quality Control Systems, aiming at providing high-quality products that fit ISO9001 Certificate for years.
2. Customized Packaging
All the products are available for customized packaging according to your demand.
3. Fast Delivery
Most efficient producing makes fast delivery, which would make sure of the lead time always ahead of your expectation.
Specification
| Contact Plating | Gold or Tin over 50μ Ni |
| Insulation Material | LCP |
| Degree of Heat-Resistant | 280°C+5°C/280°C-5°C |
| Time of Heat-Resistant | 210S |
| Terminal Type | U Type Terminal |
| Contact Material | Phosphor Copper |
Drawing
FAQ
1. Who are we?
We are based in Guangdong, China, start from 2004, sell to Southern Europe(5%), Western Europe(10%), Eastern Asia(50%), Mid East(5%), Southeast Asia(10%), Eastern Europe(5%), South America(5%), North America(10%). There are total about 101-200 people in our office.
2. What services can we provide?
Accepted Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, CNY;
Accepted Payment Type: T/T, MoneyGram, Western Union;
Language Spoken: English, Chinese
3. What is your MOQ?
The Min. order quantity is 1,000pcs, the quantity depend on the item that customers need
